Barriers
LBA 4
Boom barrier with lateral arm up to 4 m
Main advantages
Variable speed
adjustable from 2.4 to 4.4 seconds
Body
Cataphoresis treated steel
integrated equipment
Fixed tip support or tilting support
Standard equipment:
- Speed: Variable from 2.4 seconds
- Continuous and intensive operation: 10,000 cycles/day
- Arm: 84x57 mm oval lateral aluminium up to 4 m
- Geared motor: Three-phase / 230v single-phase power supply
- Housing: Cataphoresis treated steel sheet with a Ronis 405 lock + Standard RAL 5015
- Cover: 2 mm thick aluminium sheet with RAL 9010 paint
- ONE-C control board including: Power supply, PLC, frequency converter, SD card, RJ45 (Modbus) and torque limiter
- Maximum length : 4 metres
- Power supply : 230 V
- Gearmotor : Irreversible reduction gear
- Boom : 84 x 57 mm oval white lacquered aluminium
- Operation time : From 2.4 seconds
- MCBF (number of cycles) : ≥ 3 million
- MTBF (hours) : ≥ 10,000
- MTTR (min) : Less than 15 minutes
- Maximum boom length : 4 m
- Emergency operation : Irreversible geared motor: crank operation
- Temperature control : Anti-condensation heating
- Finishes : Cataphoresis treated steel housing and polyester powder coating + paint (choice of RAL colours)
- Power : 0.18 kW three-phase motor
- Foundation dimensions (LxWxH) : 600 x 600 x 800 mm
- Operating temperature : '-30° to +55° C
Customisation:
- Polyester paint with a choice of colours (RAL to be defined)
Cover with LEDs
Security:
- Infrared barrier
- Retro-reflective photoelectric cell
- Magnetic loop presence detector
- Ultrasonic detector
- Adjustable tip support with a magnetic lock - 250 kg
Options for a barrier suitable for each site
Each site has specific security, traffic, and operational constraints. LBA options allow you to configure your automatic barrier according to your needs: enhanced visibility, anti-vandalism protection, unhinging, automatic lifting, accessories, and supports.
Discover LBA options
A project? Let's talk.
Our teams guide you in defining the most suitable solution for your needs.
